  • Split Shaft AC 125V 0.3A 250V 0.6A 1 Pole 12 Positions Rotary Switch (Bag of 2)

Split Shaft AC 125V 0.3A 250V 0.6A 1 Pole 12 Positions Rotary Switch (Bag of 2)

Split Shaft AC 125V 0.3A 250V 0.6A 1 Pole 12 Positions Rotary Switch (Bag of 2)

More Views

Split Shaft AC 125V 0.3A 250V 0.6A 1 Pole 12 Positions Rotary Switch (Bag of 2)
$4.89

Availability: In stock

OR
Description

Details

Split Shaft AC 125V 0.3A 250V 0.6A 1 Pole 12 Positions Rotary Switch (Bag of 2)

Product Name Rotary Switch
Model No. RS25-1-12
Type 1 Pole 12 Positions
Rated Voltage & Current

AC 125V, 0.3A

AC 250V, 0.6A
Click Number 12
Rotational Angle Step Angle 30 Degree
Contact Resistance Less than 20mΩ
Insulation Resistance More than 100MΩ at DC500V
Withstand Voltage For 1 minute at 500V
Shaft Diameter 6mm / 0.236"
Threaded Collar Diameter 8.7mm / 0.34"
Overall Size(Approx.) 31 x 25 x 36mm / 1.2" x 1.0" x 1.4"(L*W*H)
Net Weight 23g
Package Content 2 Pcs x Rotary Switch
