  • Quick Insert 6mm Outlet Inlet Hall Effect Water Flow Sensor 0.25-3.5L/min

Quick Insert 6mm Outlet Inlet Hall Effect Water Flow Sensor 0.25-3.5L/min

Quick Insert 6mm Outlet Inlet Hall Effect Water Flow Sensor 0.25-3.5L/min

More Views

Quick Insert 6mm Outlet Inlet Hall Effect Water Flow Sensor 0.25-3.5L/min
$10.00

Availability: In stock

OR
Description

Details

Quick Insert 6mm Outlet Inlet Hall Effect Water Flow Sensor 0.25-3.5L/min

Product Name Water Flow Sensor
Model SEN-HZ06K
Flow Range 0.25-3.5L/min
Working Voltage & Current DC3V-18V, 10mA
Rated Voltage DC5V
Pulse Duty Factor 50 %
High Level of Pulse Output >4.5V
Low Level of Pulse Output <0.5V
Max Pressure 0.8Mpa
Insulation Performance(Min.) 100MΩ
Connector Type 3Pin JST Connector
Main Material POM
Total Size 85 x 40 x 22mm / 3.3" x 1.6" x 0.87""(L*W*T)
Outlet=Inlet Outer Diameter 6mm/0.24"
Cable Length 37cm / 14.6"
Body Color White
Weight 29g
Package Content 1 x Water Flow Sensor
