  • Liquid Water Level Sensor Control Floating Switch 10W AC/DC 100V OKD-1075P

Liquid Water Level Sensor Control Floating Switch 10W AC/DC 100V OKD-1075P

Liquid Water Level Sensor Control Floating Switch 10W AC/DC 100V OKD-1075P

More Views

Liquid Water Level Sensor Control Floating Switch 10W AC/DC 100V OKD-1075P
$8.75

Availability: In stock

OR
Description

Details

Liquid Water Level Sensor Control Floating Switch 10W AC/DC 100V OKD-1075P

Product Name Float Switch
Model OKD-1075P
Max Contact Rating
10W
Max Switching Voltage AC/DC 100V
Max Switching Current 0.5A
Max Breakdown Voltage DC 110V
Max Carry Current 1A
Max Contact Resistance 100mΩ
Temperature Rating -10 ~ +85 °C
Float Ball Material PP
Float Body Material Plastic
Float Ball Size(Approx) 21 x 23mm / 0.83" x 0.9"(L*D)
Thread Dia(Approx) 10mm / 0.4"
Nut Dia(Approx) 15mm / 0.6"
Bottom Clip Dia(Approx) 18mm / 0.7"
Body Total Length 90mm / 3.5"
Cable Length 30cm / 11.8"
Color White
Net Weight 60g
Package Content 1 x Float Switch
