8mm 1 4" Bore Two Position Five Way Pneumatic Solenoid Valve 24VDC 100mA

More Views

$58.30

Availability: In stock

Qty:

Description

Product Name	Solenoid Valve
Model No.	DQK-1422
Position & Way Number	2 Position 5 Way
Bore Size	8mm(1/4")
Working Medium	Clean, Compressed Air with Oil Mist
Operating Temperature Range	-10 to 55°C(without freeze)
Working Pressure	0.15-0.8MPa
Working Voltage and Current	DC 24V, 100mA
Allowance Voltage Frustration	-15 to 10%
Insulating Resistance	>=20MΩ
Effective Area	15mm2
Switching Time	>=0.04S
Mounting Hole Diameter	5.5mm / 0.216"
Threaded Hole Diameter	M12 x 1.25
Overall Size(Approx.)	108 x 82 x 120mm / 4.25" x 3.2" x 4.7"(LWH)
Weight	1005g
Package Content	1 x Solenoid Valve
