  • 13.8" Vertical Mount Liquid Water Level Sensor White Plastic Float Switch

13.8" Vertical Mount Liquid Water Level Sensor White Plastic Float Switch

13.8" Vertical Mount Liquid Water Level Sensor White Plastic Float Switch

More Views

13.8" Vertical Mount Liquid Water Level Sensor White Plastic Float Switch
$7.31

Availability: In stock

OR
Description

Details

13.8" Vertical Mount Liquid Water Level Sensor White Plastic Float Switch

Product Name Float Switch
Contacts NO+NC
Max Contact Rating
10W
Max Switching Voltage DC 100V
Max Switching Current 0.5A
Max Breakdown Voltage DC 220V
Max Carry Current 1.0A
Max Contact Resistance 100mΩ
Temperature Rating -10 ~ +60 °C / 85 °C
Float Ball Size(Approx) 23 x 21.5mm /0.91" x 0.85"(L*D)
Thread Dia(Approx) 9.5mm / 0.37"
Nut Dia(Approx) 16mm / 0.63"
Bottom Clip Dia(Approx) 17mm / 0.67"
Straight Bar Dia 8mm/0.31"
Body Total Length 118mm /4.6"
Cable Length 35cm /13.8"
Material Plastic
Color White, Black
Net Weight 17g
Package Content 1 x Float Switch
