  • 10mm x 2mm Anti Vibration Tube NO Reed Switch DC 24V 0.1A ORD211

10mm x 2mm Anti Vibration Tube NO Reed Switch DC 24V 0.1A ORD211

10mm x 2mm Anti Vibration Tube NO Reed Switch DC 24V 0.1A ORD211

More Views

10mm x 2mm Anti Vibration Tube NO Reed Switch DC 24V 0.1A ORD211
$3.52

Availability: In stock

OR
Description

Details

10mm x 2mm Anti Vibration Tube NO Reed Switch DC 24V 0.1A ORD211

Product Name Reed Switch
Model ORD211
Contact Type NO(Normal Open)
Max. Contact Rating 1W
Max. Switching Voltage DC 24V
Max. Switching Current 0.1A
Max. Carry Current 0.3A
Min. Breakdown Voltage DC 150V
Max. Initial Contact Resistance 100mOhm
Min. Insulation Resistance 1010Ohm
Max. Release Time  0.05ms
Max. Operate Time   0.3ms
Tube Size (Approx.) 10 x 2mm/ 0.4" x 0.08" (L*D)
Lead Terminal Size(Each Side) 12.5 x 0.4mm/ 0.5" x 0.016"(L*D)
Total Length (Approx.) 35mm/1.4"
Material Glass, Metal
Color Gold Tone, Clear
Weight 1g
Package Content 1 x Reed Switch
